1/2" SAE-08 1/2 Body UNF3/4"-16 Flat Face Hydraulic Coupler Skid Steer Quick Connect Disconnect Coupling ORB Bobcat Kubota
1/2" Skid Steer Bobcat Flat Face Hydraulic Coupling Technical Parameter |
||
|
Body Size: |
1/2″ Body |
|
|
Thread Size: |
1/2” SAE (¾-16” O-Ring Boss) |
|
|
Male Face Diameter: |
0.96” (24.5mm) |
|
|
FeMale Face Diameter: |
1.5” (38mm) |
|
|
PPSI Rating: |
5,000 | |
|
FFlow Rate: |
12 GPM -23GPM |
|
Standard: |
ISO 16028 |
|
|
|
|
|
1/2" Flat Face Hydraulic Coupling Interchangeable With |
||
|
|
Parker FE Series |
FEM-502-8FO | FEM-501-8FO |
|
Faster FFH Series |
FFH08 12SAE M | FFH08 12SAE F |
|
|
Stucchi FIRG Series |
803304004 | 801304035 |
|
|
Snap Tite 74 Series |
74N8-8EF | 74C8-8EF |
|
|
Dixon HT Series |
HT4OF4 | 4HTOF4 |
|
|
DNP PLT4 Series |
FF-HPG-08-08N-SAE | FF-HPG-08-08C-SAE |
|
|
|
|
|
|
|
||
|
|
|
|
|
New Valve Design and structure It Can resistance damage from high flow and the pressure of impulse that providing advanced performance. Steel construction, zinc plated with yellow chromate finish. hardened nipples and sleeves and solid barstock construction for maximum resistance to damage from hydraulic and mechanical shock.
|
|
|
Durability: Durable ball-locking mechanism assures reliable connections every time. A large number of locking balls distributes the work load evenly while providing alignment and swiveling action to reduce hose torque and prolong hose life.
|
 |
